3/4'' SCG353A043 Right Angle ASCO Type Series 353 Dust Collector Pulse Valve

3/4'' SCG353A043 Right Angle ASCO Type Series 353 Dust Collector Pulse Valve

353 Series is a high-performance pulse jet valve with threaded ports. Available with integral pilot or as a remotely piloted valve. Outlet at 90°.

Construction:
Body: Aluminium (diecast)
Ferrule: 304 SS
Armature: 430FR SS
Seals: Nitrile
Spring: 304 SS
Screw: 302 SS

Pulse jet valve, also called diaphragm valve acts as a “switch” for compressed air in the dust clean blowing system for pulse bag filters. It is controlled by the electric signals from the pulse-jet control device.Pulse jet valves are used in filtering systems of dust collectors, gas turbines, and desulfurization equipment. They are commonly used to clean filters such as cartridge filters, envelope filters, ceramic filters, and sintered metal fiber filters.

Youtube Video of SCG353A043 Right Angle Pneumatic Pulse Valve:

Technical Data:

Dimension of SCG353A043 Dust Collector Pulse Valve:

Model No.	BB11036001
Ref No.	400325
Voltage	AC24V, AC110V, AC220V, DC12V, DC24V
Connection	DIN 43650A
Other can be customized, please contact us.

Model No.	BAPC211037301
Ref No.	C113444
NC/NO	NC
2 Way or 3 Way	2Way
Other can be customized, please contact us.



Ref. Number	SCG353A043
Working Pressure	0.3~0.8Mpa
Voltage	24V DC, 110V AC, 220V AC Other voltages can be customized.
Diaphragm Nos	1
Port Size	G3/4''
Other requirement please contact.

Details About SCG353A043 Pilot Operated Solenoid Pusle Valve:

More ASCO Type Pulse Valve For You to Choose:

           Right Angle Type                        Remote Pilot Type                       Immersion Type

            Diaphragm                     Solenoid Coil                Armature Assembly            Pulse Controller
