24V DC Green Color Coil DMF Pneumatic Pulse Valve DMF-Z-40S made of ADC12 Aluminium

24V DC Green Color Coil DMF Pneumatic Pulse Valve DMF-Z-40S made of ADC12 Aluminium

    • 24V DC Green Color Coil DMF Pneumatic Pulse Valve DMF-Z-40S made of ADC12 Aluminium
    • 24V DC Green Color Coil DMF Pneumatic Pulse Valve DMF-Z-40S made of ADC12 Aluminium
    • 24V DC Green Color Coil DMF Pneumatic Pulse Valve DMF-Z-40S made of ADC12 Aluminium
    • 24V DC Green Color Coil DMF Pneumatic Pulse Valve DMF-Z-40S made of ADC12 Aluminium
    • 24V DC Green Color Coil DMF Pneumatic Pulse Valve DMF-Z-40S made of ADC12 Aluminium
  • 24V DC Green Color Coil DMF Pneumatic Pulse Valve DMF-Z-40S made of ADC12 Aluminium

    جزئیات محصول:

    Place of Origin: CHINA
    نام تجاری: BRANDO
    گواهی: CE
    Model Number: DMF-Z-40S

    پرداخت:

    Minimum Order Quantity: 1 PIECE
    قیمت: negotiation
    Packaging Details: BOX, CARTON, PALLET
    Delivery Time: 7 DAYS
    Payment Terms: Western Union, T/T
    Supply Ability: 200000PCS PER MONTH
    مخاطب
    توضیحات محصول جزئیات
    برجسته:

    pulse jet valves

    ,

    solenoid pulse valve

    24V DC Green Color Coil DMF Pulse Valve made of ADC12 Aluminium



    Pulse valve is mostly used on dust bag collector for collecting dust and remove dust, to protect enviroment and do good for enviroment and human being.

    DMF-Z-40S pulse valve with bellow specifications:

    Diaphragm Diameter (biggest position) 112mm
    Small diaphragm diameter 66mm
    Kv/Cv 45.82/53.47
    Injection Area 12~16
    Inlet/Outlet Pipe Size G 1 1/2"
    Weight 1.4 kgs


    Overall Dimensions of DMF-Z-40S:

    24V DC Green Color Coil DMF Pneumatic Pulse Valve DMF-Z-40S made of ADC12 Aluminium 0




      A B C D E F
    40 131 75 32 G 1 1/2" φ112 184


    Material Description of Each Part of DMF-Z-40S Pulse Valve:

    1, Valve Body: ADC12, Alumininum

    2, Clip: SS304

    3, Plunger tube assembly: 430FR and SS304 stainless steel

    4, Diaphragm: NBR/FKM

    5, Spring: SS304

    6, Screw: SS302



    Puls Valve Working Shop:

    24V DC Green Color Coil DMF Pneumatic Pulse Valve DMF-Z-40S made of ADC12 Aluminium 1
